Super Cell Marine Rubber Fender

The Cell Rubber Fender is a well established fender type.This fender has a hollow cylindrical body with fully rubber-embedded mounting flanges and is designed to deflect in an axial direction. Originally designed to replace cylindrical fenders, these fenders have a long track record with only some minor improvements over the years.

انکوائری بھیجنے

چیٹ اب

مصنوعات کا تعارف

The Super Cell Fender is a proven design that protects thousands of harbors around the world. Its cylindrical body resists overloading without sacrificing shear resistance.

The Cell Fender's large footprint makes installation simple. Its efficient force distribution also enables large, low hull-pressure panel designs. No other fender offers as many sizes in a full range of compounds.

SC Cell Fenders are compatible with nearly all legacy cell fenders, making them ideal for replacements and upgrades, as well as new builds.

Features

1. Easy assembly installation

2. Good shear force resistance

3. Very robust

4. A long proven track record

Specifications

SUPER CELL RUBBER FENDERS
Fender size	H	ØW	ØB	D	nxd	Bolt size	Weig
GCK400H	400	650	550	25	4x30	M22	78
GCK500H	500	650	550	25	4x32	M24	110
GCK630H	630	840	700	25	4x39	M30	230
GCK800H	800	1050	900	30	6x40	M33	410
GCK1000H	1000	1300	1100	35	6x47	M39	790
GCK1150H	1150	1500	1300	37	6x50	M42	1200
GCK1250H	1250	1650	1450	40	6x53	M45	1500
GCK1450H	1450	1850	1650	42	6x61	M52	2300
GCK1600H	1600	2000	1800	45	8x61	M52	3000
GCK1700H	1700	2100	1900	50	8x66	M56	3600
GCK2000H	2000	2200	2000	50	8x74	M64	5200
GCK2250H	2250	2550	2300	57	10x74	M64	7400
GCK2500H	2500	2950	2700	70	10x74	M64	10500
GCK3000H	3000	3350	3150	75	12x90	M76	18500
units: mm;kg/m
